Operating weight
|
6t±0.5t
|
|
Rated load
|
2t±0.5t
|
|
Bucket capacity
|
1.1m³
|
|
Engine model
|
SL4105ABK
|
|
Rated engine power
|
56KW
|
|
Rated rotate speed
|
2400r/min
|
|
Max.torque
|
221.9N.m
|
|
Breakout force
|
98KN
|
|
Driving speed
|
|
|
Forward Ⅰ
|
0-9km/h
|
|
Forward Ⅱ
|
0-22km/h
|
|
Reverse Ⅰ
|
9.5km/h
|
|
Reverse Ⅱ
|
30km/h
|
|
Gradeability
|
28°
|
|
Overall length
|
5930mm±20mm
|
|
Overall width
|
1900mm±20mm
|
|
Overall height
|
2830mm±20mm
|
|
Wheel base
|
2100mm±15mm
|
|
Track base
|
1490mm±15mm
|
|
Min.ground clearance
|
450mm
|
|
Max.dumping height
|
2750mm±20mm
|
|
Max.dumping reach
|
895mm±20mm
|
|
Raise time
|
5s
|
|
Total
|
10s
|
|
Tyre type
|
16/17-20
|
|
