No |
Item |
Unit |
|
|
1 |
Overall length |
mm |
9680 |
|
2 |
Overall width |
mm |
3120 |
|
3 |
Overall height |
mm |
3640 |
|
4 |
Load center |
mm |
600 |
|
5 |
Self weight |
kg |
31000 |
|
6 |
Max. load (lift height≤1500mm) |
kg |
33000 |
|
7 |
Rated load |
kg |
28000 |
|
8 |
Max. lift height (fork) |
mm |
2525 |
|
9 |
Max. lift height (mast) |
mm |
3795 |
|
10 |
Max. front overhang |
mm |
1660 |
|
11 |
Max. lift speed (unladen/laden) |
mm/s |
390/385 |
|
12 |
Max. down speed (unladen/laden) |
mm/s |
372/500 |
|
13 |
Fork tilt angle (Front/Rear) |
(°) |
33.5/11.0 |
|
14 |
Fork size (L×W×H) |
mm |
1600×250×100 |
|
15 |
Fork distance |
mm |
250-1330 |
|
16 |
Turn angle (Left/Right) |
(°) |
32/32 |
|
17 |
Min. turn diameter (front center) |
m |
18.35 |
|
18 |
Min. turn diameter (fork) |
m |
19.75 |
|
19 |
Min. ground clearance |
mm |
445 |
|
20 |
Gradeability (laden) |
(°) |
20 |
|
21 |
Max. pull force |
kn |
173.6 |
|
22 |
Wheelbase |
mm |
4142 |
|
23 |
Tread (F/R) |
mm |
2390/2390 |
|
24 |
Front overhang |
mm |
1480 |
|
25 |
Rear overhang |
mm |
2460 |
|
26 |
Departure angle |
(°) |
21.7 |
|
27 |
Travel speed |
F Ⅰ/Ⅱ |
km/h |
14.29/31.25 |
|
R Ⅰ |
18.48 |
