Operating weight
|
10.4T
|
|
Rated load
|
3T
|
|
Bucket capacity
|
1.7m³
|
|
Engine model
|
WP6G125E22
|
|
Rated engine power
|
92KW
|
|
Rated rotate speed
|
2300r/min
|
|
Max.torque
|
500N.m
|
|
Breakout force
|
98KN
|
|
Driving speed
|
|
|
Forward Ⅰ
|
8km/h
|
|
Forward Ⅱ
|
13.5km/h
|
|
Forward Ⅲ
|
25km/h
|
|
Forward IV
|
36km/h
|
|
Reverse Ⅰ
|
9.5km/h
|
|
Reverse Ⅱ
|
30km/h
|
|
Gradeability
|
28°
|
|
Overall length
|
7200mm±20mm
|
|
Overall width
|
2250mm±20mm
|
|
Overall height
|
3220mm±20mm
|
|
Buchet width
|
2300mm±10mm
|
|
Wheel base
|
2750mm±15mm
|
|
Track base
|
1800mm±10mm
|
|
Min.ground clearance
|
450mm
|
|
Max.dumping height
|
3400mm±30mm
|
|
Max.dumping reach
|
1290mm±20mm
|
|
Raise time
|
≤6.8s
|
|
Total
|
≤12.5s
|
|
Tyre type
|
17.5-20
|
|
