Engine |
|
Rated power |
175kw |
Overall dimensions
|
|
Overall length |
8385mm |
|
Overall width |
3074mm |
|
Overall height |
3400mm |
|
Dumping height |
3200mm |
|
Dumping reach |
1270mm |
|
Specification of tires |
26.5-25 |
|
Wheel base |
3350mm |
|
Tire width |
2250mm |
|
Performance parameters of entire machine |
|
Operating weight |
≤ 19000KGS |
|
Bucket capacity |
3.5m3 |
|
Rated loading capacity |
6000KGS |
|
Max. Climbing Gradient |
30o |
|
Rated output/speed |
175KW/2200r/min |
|
Engine model |
WD240E21 |
|
Lifting time |
≤ 6s |
|
Total cylinder time |
≤ 11s |
|
Travel speed |
|
Forward gear Ⅰ |
11km/h |
|
Forward gear Ⅱ |
38km/h |
|
Reverse gear Ⅰ |
16km/h |
|
