Operating weight
|
17±0.5T
|
|
Rated load
|
5T
|
|
Engine model
|
WD10G220E11
|
|
Rated engine power
|
162KW
|
|
Rated rotate speed
|
2200r/min
|
|
Max.torque
|
≥745.3N.m
|
|
Breakout force
|
145KN
|
|
Driving speed
|
|
|
Forward Ⅰ
|
0-11.5km/h
|
|
Forward Ⅱ
|
0-38km/h
|
|
Reverse Ⅰ
|
0-16km/h
|
|
Gradeability
|
28°
|
|
Overall length
|
7950mm±20mm
|
|
Overall width
|
2870mm±20mm
|
|
Overall height
|
3500mm±20mm
|
|
Wheel base
|
3300mm±15mm
|
|
Track base
|
2260mm±10mm
|
|
Min.ground clearance
|
470mm
|
|
Max.dumping height
|
3300mm±30mm
|
|
Max.dumping reach
|
1400mm±20mm
|
|
Torque converter
|
Single stage,4elements
|
|
NO.of shifts
|
1Forwards2/Reverse 1
|
|
Transmission
|
Planet-type
|
|
Raise time
|
≤6.8s
|
|
Total
|
≤12.5s
|
|
Tyre type
|
23.5-25
|
|
